24GHz 15m Radar Induction Single Channel Microwave Sensor Module Cdm324

$40.95
FREE Shipping

24GHz 15m Radar Induction Single Channel Microwave Sensor Module Cdm324

  • Brand: Unbranded
  • product image
  • product image
  • product image
  • product image
  • product image
24GHz 15m Radar Induction Single Channel Microwave Sensor Module Cdm324

24GHz 15m Radar Induction Single Channel Microwave Sensor Module Cdm324

  • Brand: Unbranded
Price: $40.95
Sold by:
$40.95
FREE Shipping

In stock

We accept the following payment methods

Description

Feature:Non-contact detection,moving object detecting 2This module's transmitting frequency is 24GHZ, can be widely applied in business, industries, word controlling etc 3Provide various frequency range standards:-UK,-F 4Advanced low consumption PHEMT oscillator 5Independent transmitting and receiving route, can get the big gain Features: Non-contact detection, moving object detecting. This module's transmitting frequency is 24GHZ, can be widely applied in business, industries, word controlling etc. Provide various frequency range standards: -UK,-F. Advanced low consumption PHEMT oscillator. Independent transmitting and receiving route, can get the big gain. High sensibility, high flexibility, low cost, operating distance is 15m. Single channel operation. Specifications: Transmitting Frequency: min:24GHz ; typ:24.125GHz max:24.25GHz Output Power:16dbm (typ) Antenna pattern: horizontal direction: typ.80, vertical direction: typ.32 Side lobe suppression ratio: horizontal direction: typ.13dB, vertical direction: typ.13dB Operating Temperature:-20~60 Operating Current: typ:30MA, max:40MA Operating Voltage: typ:5.5V Pulse Width: typ:10US IF Output:-300~300MV Size: 25 x 25 x 7mm/0.98 x 0.98 x 0.27inch Weight: 5g Package Included: 1 x Microwave Body Induction Module
  • Fruugo ID: 429985933-903145127
  • EAN: 5436933231269

Product Safety Information

Please see the product safety information specific to this product outlined below

The following information is provided by the independent third-party retailer selling this product.

Safety Warnings: Not suitable for children under three years old
Manufacturer Part Number: 5436933231269
Model Number: 5436933231269
Serial Number: 5436933231269
Batch Number: 5436933231269
